Amortisseur Arrière

Fox Float DPS Performance, 205x65mm. Settings: Compression 3 positions lever, low-speed rebound,air preload. Trunnion top mount, 25x10mm bottom bushings

Cadre

Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

Cassette

Sram PG-1210, 11-50T, 12s

Catégorie principale

Hardgoods

Chaine

Sram SX Eagle, 12s, Powerlock

Dérailleur arrière

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Entraînement

Bosch Performance Line CX (25Km/h) GEN4 BS3/ Intuvia 50 / V2 Intuvia 100 / Bosch Mini Remote / Bosch System Controller

Fourche

Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload

Freins

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Guidon

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9° backsweep, 5° upsweep,31.8mm barbore

Jantes

Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Jeu de Direction

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°,bottom 51.9x40x8x45°x45°

Leviers de Vitesse

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Matérial du cadre

Aluminium

Moyeu Arrière

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts

Moyeu Avant

Mavic, Boost 15x110mm, IS 6 bolts

Batterie

Bosch Powertube 750Wh

Pneus

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Poignées

Onoff Twin, 1lock-on, 135mm

Potence

Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore

Pédales

-

Pédalier

Race Face Aeffect ebike, 165mm

Selle

MDK ebike black

Sous-groupe de marchandise

VTT électriques

Sport

E-Bike

Taille

S M L XL

Taille de roue

29

Tige de Selle

Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size:498x140-170mm, XL size: 498x140-170mm

Unité de vente

pièce
